Advance Appliances Electric Thermal Store Indirect TSI210 with Cold Section
- SKU
- EDDAA17
Our Expert's Opinion
"High quality, British made appliances."Advance Appliances TSi210 210 Litre Indirect Thermal Store
The Advance Appliances TSi210 is a 210 litre indirect twin coil vented thermal store for use with a gas, oil, solid fuel or biomass boiler. It stores central heating water and passes mains water through an internal coil, giving mains pressure hot water for powerful showers and quick bath filling without the need for an unvented cylinder.
How it works
In the indirect pattern the boiler heats the store through the lower coil, so it can be used with a sealed system boiler in a Y plan with a single pump. The store stays vented and its water is used only to carry heat.
The indirect pattern can be sited anywhere in the property.
Cold section
This model has an integrated feed and expansion (cold) section on top.
Replacing an older store
Advance thermal stores are a like-for-like replacement for Boilermate, Flomax and Albion Mainsflow stores. Made in the UK and built to the HWA specification.
Specification
- Capacity: 210 litres
- Type: vented thermal store, indirect twin coil, with integrated feed and expansion tank
- Suits: 2 baths and 1 shower
- Minimum boiler size: 24kW
- Heat loss: 58W (class B)
- Low maintenance, pre-plumbed unit (Advance Appliances)
- Flow rate: up to 30 litres per minute (Advance Appliances)
- Stainless steel store with 22mm hot and cold connections
- Fitted with a hot water control pack and immersion heater backup
- For gas, oil, solid fuel or biomass boilers (not heat pumps)
- Warranty: 10 years on the store, 2 years on fitted components (Advance Appliances)
Installation
Installation by a qualified heating engineer is required. Check the minimum boiler size before ordering; a smaller boiler will lengthen recovery times.
Need help choosing? Call our team on 01934 253600 or email [email protected].
| MPN | TSI210 |
|---|---|
| Product Code | EDDAA17 |
| Height (mm) | 1735 |
| Width (mm) | 600 |
| Depth (mm) | 600 |
| Capacity | 210 |
| Power (Watts) | 3000 |
| Heater Type | Thermal Store |
| Warranty (years) | 2 |
| Energy Performance Rating | B |
| Empty Weight (kG) | 55 |
| Full Weight (kG) | 265 |
| Brand | Advance Appliances |
