Altecnic 309547CST 4 Bar T&P Relief Valve 3/4" x 15mm Long Probe | Genuine Replacement Spare Part
- SKU
- EDDALTECNIC28
Genuine Altecnic 309547CST 4 Bar T&P Relief Valve 3/4" x 15mm Long Probe
Long probe version, factory set to 4 bar and 90 C with a 200mm probe for deeper immersion into the cylinder.
Where it fits
Unvented hot water storage cylinders and domestic hot water storage heaters - the temperature and pressure relief valve limits stored water to its set temperature and pressure - 4 bar, 90 C, long 200mm probe, 10 kW discharge.
Specification
- Series 309
- Set pressure 4 bar
- Set temperature 90 C
- Probe length 200mm
- Discharge rating 10 kW
- Inlet 3/4" M BSP
- Outlet 15mm compression
- Max working pressure 10 bar
- PED category IV
- WRAS approved
Installation
G3 qualified installation required (Building Regulations Part G, unvented hot water storage). As a genuine Altecnic part it is built to the original Caleffi specification for a reliable, like-for-like replacement. In stock at Electrical Deals Direct.
| MPN | 309547 CST |
|---|---|
| Product Code | EDDALTECNIC28 |
| Compatible With: Product Code (SKU) | Unvented hot water storage cylinders and domestic hot water storage heaters; the temperature and pressure relief valve limits stored water to its set temperature and pressure; 4 bar, 90 C, long 200mm probe, 10 kW discharge |
| Part Origin | Genuine |
| Part or Accessory? | Part |
| Brand | Altecnic |
